Feature:

1.The latest computer control system is adopted, capable of spraying strip-shaped, mist-like patterns, and even fonts or logos. It saves glue, provides strong adhesion, and eliminates missed spots.

2.High computer positioning accuracy.

3.Simple to use, easy to operate, and highly efficient, with a daily output of up to around 7,000 units.

4.User-friendly design, easy to adjust, and supports graphic import.

5.Wider application range, suitable for irregular boxes, crafts, gift boxes, and can be quickly and conveniently used for production, providing users with more diversified product options.

6.Easy maintenance, simple to understand and learn, with stable performance, consistently receiving positive feedback from both domestic and international users.



Technical Parameters:

Model

FT-1100

Machine Size

9000x3500x1900mm

Machine Weight

2000KG

Air Pressure

0.7MPa

Machine Power

25kw   380v

Production speed

0-15pcs\min

Maximum shell size per station

1050x500mm

Minimum shell size per station

500x200mm

Maximum inner box

500*150mm

Minimum inner box

180*40mm

Positioning accuracy

±0.3mm



التعليمات

Q1: هل أنت مصنع أو شركة تجارية؟
ج: لدينا مصنعنا الخاص، الذي يقع في Wuxi، مع تدقيق GRS وBSCl وSEDEX لأكثر من 5 سنوات. يمكننا تقديم خدمة OEM بما في ذلك الحجم المخصص وتصميم الشعار.
Q2: ماذا عن مراقبة الجودة لشركتك؟
ج: نحن نولي اهتمامًا كبيرًا لمراقبة الجودة من البداية إلى النهاية، وسيقوم قسم مراقبة الجودة لدينا بفحص جميع البضائع بدقة قبل تسليم الشحنة. نرحب بفحص الطرف الثالث.
Q3: متى هو وقت التسليم الخاص بك ؟
ج: في غضون 30 يومًا بعد الطلب.
س 4: هل من المناسب إنشاء اسم العلامة التجارية للعميل؟
ج: نعم، OEM موضع ترحيب إذا كانت الكمية أعلى من موك.
س 5: أين هو ميناء التحميل الخاص بك؟
ج: شنغهاي، الصين.
س 6: هل تقدمون عينات مجانية؟
ج: نعم ، ستكون عينات المخزون المجانية متاحة ، ولكن سيتم تغطية تكلفة الشحن من قبل العملاء. يرجى الاتصال بنا للتحقق من تكلفة الشحن وفقًا لعنوان العميل.
